Service Module
Our fully baffled service modules are fabricated from mild steel plate with a minimum thickness of 6 mm. All welding is compliant with AS1554.1, and all module compartments are pressure tested to confirm weld integrity. The module is mounted to the cab chassis using heavy duty mounts that restrain the module without negatively affecting the compliance of the cab chassis. The module layout is designed to be compatible with a range of cab chassis to meet your specific requirements.
Tank Level Gauging & Overfill Protection
Tank levels and product volumes are gauged by level sensor, processed by PLC, and conveniently displayed via touch screen located in the truck’s cab. PLC controlled solenoid valves located at the tank fill point prevent overfilling of the oil, coolant and waste oil tanks. A Hydrau-Flo fast filling fuel system prevents the diesel tank being overfilled and a Modulube V96 prevents overfilling of the grease tank.
Product Containment
Oil, coolant and waste oil tanks vent via an innovative system requiring a single desiccant breather. In the event of sensor failures of a type that comprises the PLC based overfill protection, this system prevents over pressuring of tanks as well as cross-contamination via backflow. At the same time, it ensures that any excess product remains contained within the reel cabinet
Improved Handling & Serviceability
The reel cabinet is designed to run the width of the service truck to ensure axle loads on both sides of the truck are balanced, thereby reducing wear and tear on the cab chassis and resulting in improved dynamic handling. Roller shutters permit access to the reel cabinet from both sides of the truck, significantly improving the ease of servicing and maintenance activities.
